General Information
Manufacturer Fujitsu
Year 2017
Socket(s) 1x LGA 2066
Form Factor ATX
244 x 305 mm
Chipset Intel C422
Market Industrial
MSRP US $?
Product Page Go to website
Comparison feature is in beta and not finished!

Back IO
Audio

  • 3x Analog Audio Jack
Misc

  • 2x PS/2
Network

  • 2x RJ-45
USB

  • 6x USB 3 Gen 1 Type-A
  • 1x USB 3 Gen 2 Type-A
  • 1x USB 3 Gen 2 Type-C

Internal Connections
Misc

  • 1x Chassis Intrusion Header
  • 1x Serial Header
  • 1x TPM Header
Power

  • 1x 24-pin ATX Power
  • 1x 8-pin 12V Power
Storage

  • 8x SATA3
USB

  • 1x USB 2 Header
  • 1x USB 2 Type-A
  • 2x USB 3 Gen 1 Header

Misc. Information
PCB Color Green
Other Colors
  • Black
  • Blue

Network
Wired
Amount Chip Speed For IPMI
1x Intel I219-LM 1000 Mbit No
1x Intel I210-AT 1000 Mbit No

Expansion Slots
Slots

  • 2x PCI-E 3.0 x16 @ x16
  • 1x PCI-E 3.0 x8 @ x8
  • 2x PCI-E 3.0 x8 @ x4
  • 2x PCI-E 3.0 x8 @ x1
Crossfire & SLI
AMD Crossfire No
Nvidia SLI No

Audio
Audiochip Realtek ALC671
Audio Channels 5.1

Memory

This board has 8 slots with the following specifications:

Slot Protocol DDR4
Slot Type 288-pin DIMM
Maximum Speed 2666 MHz
Maximum Capacity 512 GB
Maximum Channels 4
ECC support Yes

M.2 Slots
M.2 Connections
Amount Slot Sizes Speeds
1x M-Key 2260, 2280, PCI-E 3.0 x4,
