General Information
Manufacturer MSI
Year 2011
Socket(s) 1x LGA 2011
Form Factor XL-ATX
264 x 345 mm
Chipset Intel X79
Market Consumer
MSRP US $?
Product Page Go to website
Comparison feature is in beta and not finished!
Back IO
Audio
  • 6x Analog Audio Jack
  • 1x Coaxial SPDIF Out
  • 1x Optical SPDIF Out
Misc
  • 1x PS/2
Network
  • 2x RJ-45
Storage
  • 1x FireWire 400 6-pin
USB
  • 6x USB 2 Type-A
  • 4x USB 3 Gen 1 Type-A

Internal Connections
Fans
  • 6x 4-pin Fan Header
Misc
  • 1x Chassis Intrusion Header
Power
  • 1x 24-pin ATX Power
  • 2x 8-pin 12V Power
Storage
  • 1x FireWire 400 Header
  • 4x SATA2
  • 6x SATA3
USB
  • 2x USB 2 Header
  • 1x USB 3 Gen 1 Header

Misc. Information
PCB Color Black
Other Colors
  • Black
  • Copper

Network
Wired
Amount Chip Speed For IPMI
1x Intel 82579V 1000 Mbit No
1x Intel 82574L 1000 Mbit No

Expansion Slots
Slots
  • 2x PCI-E 3.0 x16 @ x16
  • 2x PCI-E 3.0 x16 @ x8
  • 3x PCI-E 2.0 x16 @ x1
Crossfire & SLI
AMD Crossfire No
Nvidia SLI No

Audio
Audiochip Realtek ALC898
Audio Channels 7.1

Memory

This board has 8 slots with the following specifications:

Slot Protocol DDR3
Slot Type 240-pin DIMM
Maximum Speed 2400 MHz
Maximum Capacity 128 GB
Maximum Channels 4
ECC support No
