General Information
Manufacturer MSI
Year 2017
Socket(s) 1x AM4
Form Factor ATX
Chipset AMD X370
Market Consumer
MSRP US $?
Product Page Go to website
Comparison feature is in beta and not finished!

Back IO
Audio

  • 5x Analog Audio Jack
  • 1x Optical SPDIF Out
Misc

  • 1x PS/2
Network

  • 1x RJ-45
USB

  • 3x USB 2.0 Type-A
  • 4x USB 3.0 Type-A
  • 1x USB 3.1 Gen-2 Type-A
  • 1x USB 3.1 Gen-2 Type-C
Video

  • 1x DisplayPort
  • 1x HDMI Out

Internal Connections
Fans

  • 6x 4-pin Fan Header
Misc

  • 1x 2-pin Slow Mode Header
  • 1x Chassis Intrusion Header
  • 1x RGB Header
  • 1x TPM Header
Power

  • 1x 24-pin ATX Power
  • 1x 4-pin 12V Power
  • 1x 6-pin 12V Power
  • 1x 8-pin 12V Power
Storage

  • 6x SATA3
  • 1x U.2
USB

  • 2x USB 2.0 Header
  • 2x USB 3.0 Header
  • 1x USB 3.1 Gen-2 Header

Misc. Information
PCB Color Silver
Other Colors
  • Black
  • Silver

Network
Wired
Amount Chip Speed For IPMI
1x Intel I211-AT 1000 Mbit No

Expansion Slots
Slots

  • 2x PCI-E 3.0 x16 @ x16
  • 1x PCI-E 2.0 x16 @ x4
  • 3x PCI-E 2.0 x1 @ x1
Crossfire & SLI
AMD Crossfire Yes
Nvidia SLI Yes

Audio
Audiochip Realtek ALC1220
Audio Channels 7.1

Memory

This board has 4 slots with the following specifications:

Slot Protocol DDR4
Slot Type 288-pin DIMM
Maximum Speed 3200 MHz
Maximum Capacity 64 GB
Maximum Channels 2
ECC support No

M.2 Slots
M.2 Connections
Amount Slot Sizes Speeds
1x M-Key 22110, 2242, 2260, 2280, PCI-E 3.0 x4, SATA3,
1x M-Key 2242, 2260, 2280, PCI-E 2.0 x4, SATA3,

Reviews
Reviewer Review Language Review Type Review Date
Play3r English Video March 6, 2017 View Review
AdoredTV English Video March 21, 2017 View Review
NeoSeeker English Video March 30, 2017 View Review
Guru3D English Video April 5, 2017 View Review
Hardwareluxx German Video April 14, 2017 View Review
KitGuru English Video May 30, 2017 View Review
