General Information
Manufacturer Asrock
Year 2016
Socket(s) 1x LGA 2011-3
Form Factor ATX
244 x 305 mm
Chipset Intel X99
Product Series Asrock Fatal1ty
Market Consumer
MSRP US $?
Manual Download Manual
Product Page Go to website
Comparison feature is in beta and not finished!

Back IO
Audio

  • 5x Analog Audio Jack
  • 1x Optical SPDIF Out
Misc

  • 1x PS/2
Network

  • 2x RJ-45
USB

  • 2x USB 2.0 Type-A
  • 4x USB 3.0 Type-A
  • 1x USB 3.1 Gen-2 Type-A
  • 1x USB 3.1 Gen-2 Type-C

Internal Connections
Fans

  • 5x 4-pin Fan Header
Misc

  • 1x Serial Header
  • 1x TPM Header
Power

  • 1x 24-pin ATX Power
  • 1x 8-pin 12V Power
Storage

  • 1x SATA Express
  • 10x SATA3
USB

  • 2x USB 2.0 Header
  • 2x USB 3.0 Header

Misc. Information
PCB Color Black
Other Colors
  • Black
  • Red

Network
Wired
Amount Chip Speed For IPMI
1x Intel I218-V 1000 Mbit No
1x Intel I211-AT 1000 Mbit No

Wireless

Bluetooth Version 4.0
Wifi 5GHz Support Yes
Wifi Protocol 802.11 a/b/g/n/ac

Expansion Slots
Slots

  • 3x PCI-E 3.0 x16 @ x16
  • 2x PCI-E 2.0 x1 @ x1
Crossfire & SLI
AMD Crossfire Yes
Nvidia SLI Yes

Audio
Audiochip Realtek ALC1150
Audio Channels 7.1
Headphone Amplifer Texas Instruments NE5532

Memory

This board has 8 slots with the following specifications:

Slot Protocol DDR4
Slot Type 288-pin DIMM
Maximum Speed 3300 MHz
Maximum Capacity 256 GB
Maximum Channels 4
ECC support Yes

M.2 Slots
M.2 Connections
Amount Slot Sizes Speeds
1x M-Key 22110, 2230, 2242, 2260, 2280, PCI-E 3.0 x4, SATA3,
1x M-Key 2230, 2242, 2260, 2280, PCI-E 3.0 x4, SATA3,
1x E-Key 2230, For Wifi Module Only

Reviews
Reviewer Review Language Review Type Review Date
TweakTown English Written Aug. 9, 2016 View Review
KitGuru English Written Sept. 8, 2016 View Review
TechPowerUp English Written Nov. 18, 2016 View Review
