General Information
| Manufacturer | Asrock |
|---|---|
| Year | 2014 |
| Socket(s) |
1x
LGA 2011-3
|
| Form Factor | ATX |
| Chipset | Intel X99 |
| Product Series | Asrock Fatal1ty |
| Market | Consumer |
| MSRP | US $? |
| Manual | Download Manual |
| Product Page | Go to website |
Back IO
Audio
- 5x Analog Audio Jack
- 1x Optical SPDIF Out
Misc
- 1x PS/2
Network
- 2x RJ-45
Storage
- 1x eSATA3
USB
- 2x USB 2 Type-A
- 6x USB 3 Gen 1 Type-A
Internal Connections
Fans
- 4x 3-pin Fan header
- 2x 4-pin Fan Header
Misc
- 1x HDD Saver Header
- 1x Serial Header
- 1x TPM Header
- 1x Thunderbolt 5-pin Header
Power
- 1x 24-pin ATX Power
- 1x 8-pin 12V Power
- 1x Molex Power
Storage
- 10x SATA3
USB
- 2x USB 2 Header
- 2x USB 3 Gen 1 Header
- 1x USB 3 Gen 1 Type-A
Misc. Information
| PCB Color | Black |
|---|---|
| Other Colors |
|
Network
Wired
| Amount | Chip | Speed | For IPMI |
|---|---|---|---|
| 1x | Intel I218-V | 1000 Mbit | No |
| 1x | Killer E2200 | 1000 Mbit | No |
Expansion Slots
Slots
- 2x PCI-E 3.0 x16 @ x16
- 1x PCI-E 3.0 x16 @ x8
- 2x PCI-E 2.0 x1 @ x1
- 1x PCI-E 2.0 Mini PCI-E @ x1
Crossfire & SLI
| AMD Crossfire | Yes |
| Nvidia SLI | Yes |
Audio
| Audiochip | Realtek ALC1150 |
|---|---|
| Audio Channels | 7.1 |
| Headphone Amplifer | Texas Instruments NE5532 |
Memory
This board has 8 slots with the following specifications:
| Slot Protocol | DDR4 |
|---|---|
| Slot Type | 288-pin DIMM |
| Maximum Speed | 3000 MHz |
| Maximum Capacity | 256 GB |
| Maximum Channels | 4 |
| ECC support | Yes |
M.2 Slots
M.2 Connections
| Amount | Slot | Sizes | Speeds |
|---|---|---|---|
| 1x | M-Key | 22110, 2230, 2242, 2260, 2280, | PCI-E 3.0 x4, |
Reviews
| Reviewer | Review Language | Review Type | Review Date | |
|---|---|---|---|---|
| TweakTown | English | Video | Aug. 29, 2014 | View Review |
